Features:

• Low narrow design for confined bilge spaces
• Easy installation - outlet and pump body rotate to suit your installation (vertical or horizontal outlet)
• High flow rates - Available in 650 and 1100 GPH models
• Efficient operation - Very low power consumption
• Low profile strainer - Leaves the bilge almost dry
• Easy to clean – snap fit assembly – unique clever strainer design – easy to remove and replace for cleaning
• No separate bilge switch required
• Unaffected by wave motion – optimized on/off timings prevent run on
• Environmentally friendly - mercury free
• Solid state switching - no moving parts
• Includes manual override facility

Specifications:

• Open Flow Rate: 650 GPH (40 ltrs/min)
• Flow Rate 1m Head: 550 US GPH (34 ltrs/min)
• Nominal Voltage: 12 Vdc
• Current Draw: 3.4 amps
• Recommended Fuse Size: 5 amp
• Weight: 0.326 kg (0.71 lbs)
• Maximum Discharge Head: 3 m (10 ft.)
• Hose Connections: 19 mm (¾") / 25 (1") Stepped port
• Overall height: 75 mm (3”)
• Overall Width: 54 mm (2 ")
• Overall Length: 212 mm (8 ")
