WB20X - 2 inch, 118cc 152 gal per minute Centrifugal, Self-priming Water Pump

Engine GX120, 4.0 HP, OHV Displacement 118 cc Bore and Stroke 2.4" x 1.7" Compression Ratio 8.5:1 Oil Alert Standard Pump Type Centrifugal, Self-Priming Volute Rigid Mounted Cast Iron Impeller Cast Iron Mechanical Seal silicone Carbide/Silicon Carbide Priming Time 110 sec. at 16.4 ft. Drive System Direct Discharge Capacity 152 gals./min. Suction Port Diameter 2.0" NPT Discharge Port Diameter 2.0"" NPT Total Head Lift 92 ft. Suction Head Lift 26 ft. Maximum Pressure 40 psi Solids Handling N/A Dimensions 17.90" x 14.4" x 16.5" Dry Weight 46.0 lbs Optional Strainer Part # 78325-YG3-000

Honda's OHV Engine Cast Iron Impeller and Volute Abrasion-Resistant silicone Carbide Seal 2" Suction/Discharge Ports Heavy-Duty Full Frame Protection Pumps up to 152 Gallons/Minute Lightweight Aluminum Pump Case Rubber Mounts Minimize Vibration 3 Year Residential Warranty 1 Year Commercial Warranty

Honda's general purpose pumps offer the best features at a value price: Honda easy starting GX commercial grade engines Full frame protection Fixed-mounted cast iron volute and impeller Silicon-carbide seals Anti-vibration mounts Rugged performance Add in a full 3 year warranty, and you've got a pump that's unmatched in quality and value.

Pump Type - Centrifugal, Self-priming

Specifications / Manuals
